Model: F85
Model: B120T
Model: S400T
Model: B30
- Maximum number of plates (NoP) 160
- Max flow 17 m³/h (74.85 gpm)
- Channel volume 0.094/0.094 dm³ (0.0033/0.0033 ft³)
- Material 316/316L stainless steel plates, copper brazing
- Weight excl. connections 2.09+(0.1492*NoP) kg
- 4.60+(0.329*NoP) lb
Model: B120T
- Maximum number of plates (NoP) 250
- Max flow 27.4 m³/h (120.64 gpm)
- Channel volume 0.241/0.241 dm³ (0.0085/0.0085 ft³)
- Material 316/316L stainless steel plates, copper brazing
- Weight excl. connections 8.33+(0.404*NoP) kg
- 18.36+(0.891*NoP) lb
Model: S400T
- Maximum number of plates (NoP) 280
- Max flow 83 m³/h (365.44 gpm)
- Channel volume 0.403/0.403 dm³ (0.0142/0.0142 ft³)
- Material 316/316L stainless steel plates, copper brazing
- Weight excl. connections 15.43+(0.7*NoP) kg
- 34.02+(1.543*NoP) lb
Model: B30
- Maximum number of plates (NoP) 300
- Max flow 27 m³/h (118.88 gpm)
- Channel volume 0.097/0.081 dm³ (0.0034/0.0029 ft³)
- Material 316/316L stainless steel plates, copper brazing
- Weight excl. connections 5.88+(0.18*NoP) kg
- 12.96+(0.397*NoP) lb
